MCK Basic Series
DL-240W-MCK
Power: 240W
Series: Constant current type
Application: street lights, tunnel lights, floodlights, linear lights, shoebox lights, etc.
Certificates: CE, FCC, SAA, CLASS P, UL
Warranty: 5 years
- Features
- Selection Table
- Packaging & Structure
- Downloads
Class I structure
Input voltage: 120-277V～ 50/60Hz
Efficiency 95% (Typ.)
Constant power drive, constant current output control mode
Metal shell structure, protection level: IP42
Lightning protection level: differential mode 6kV, common mode 10kV
| Product Model | Rated power | Input voltage | Output voltage | Constant power voltage | Output current | efficiency | PF value | Lightning protection level | Product size |
| DL-240W-V260A-MCK | 240W | 120-277V | 180-260V | 200-260V | 0.75-1.25A | 95.0% | 0.95 | 6/10KV | L173*W57*H37 |
| DL-240W-V260S-MCK | 240W | 120-277V | 180-260V | 200-260V | 0.75-1.25A | 95.0% | 0.95 | 6/10KV | L173*W57*H37 |
| DL-240W-V260X-MCK | 240W | 120-277V | 180-260V | 200-260V | 0.75-1.25A | 95.0% | 0.95 | 6/10KV | L173*W57*H37 |
| The overall dimensions of the packaging box are (unit: mm) | L475*W360*H205 |
| The number of products packaged per box | 32 pieces/box |
| Net weight of single machine | 0.58Kg |
| Full container gross weight | 18.81Kg |
