MXS-H series
DL-680H-MXS
Power: 680W
Series: Constant Current Type
Applications: Plant lighting, sports lighting, etc.
Certificates: CB, CE, CCC, ENEC, SAA, FCC, UL
Warranty: 5 years
- Features
- Selection Table
- Packaging & Structure
- Downloads
Class I Structure
Input voltage: 200-277V～ 50/60Hz
Efficiency 94.5% (Typ.)
Constant power drive, constant current output control mode
Metal casing structure, protection rating: IP67
Lightning protection rating: Differential mode 6KV, Common mode 15KV
| Product Model | Rated power | Input voltage | Output voltage | Constant power voltage | Output current | efficiency | PF value | Lightning protection level | Product Dimensions |
| DL-680H-56X-MXS | 680W | 200-277V | 36-56V | 46-56V | 11~14.8A | 94.5% | 0.95 | 6/15KV | 265*90*44.5mm |
| DL-680H-56J-MXS | 680W | 200-277V | 36-56V | 46-56V | 11~14.8A | 94.5% | 0.95 | 6/15KV | 275*90*44.5mm |
| DL-680H-56JS-MXS | 680W | 200-277V | 36-56V | 46-56V | 11-14.8A | 94.5% | 0.95 | 6/15KV | 275*90*44.5mm |
| The external dimensions of the packaging box are (unit: mm). | L475*W350*H205 |
| Quantity of products per box | 6 pieces/box |
| Single unit net weight | 2.58Kg |
| Gross weight of the whole box | 15.73Kg |
